Application:
Appropriate for use in solar power applications that require 1000 or 2000 volt raing. For use in grounded and ungrounded photovoltaic power systems.
Construction:
Staranded bare and tinned copper conductors per ASTM B-3, B-8.
Chemically Cross-linked poyethylene insulation.
Available Colors: Black, Green, White, Red.
Print on one side with a contrasting ink. An extruded stripe and other coloer are available upon request.
Standards:
UL 4703 Type PV
National Electrical Code(NEC)
ICEA S-95-658/NEMA WC70
UL 44 Type RHH or RHW-2
UL 854 Type USE-2 for 600V
c(UL) RWU90 1KV(-40℃)
Other Compliances:
EPA 40 CFR, Part 261 for leachable lead content per TCLP
OSHA Acceptable
RoHS Compliant, Sun Res, Gas and Oil Resistant II
Option:
UL 1581 VW-1 compliance available on request
19 strand conductors available on request
PACKAGING:
Material cut to length and shipped on non-returnable wood reels or steel reels.
