Aluminum XHHW-2 Power Cable Low Friction 600V/1000V

Application:

Low Friction type XHHW-2 is primarily used in house construction, conduit, or recognized raceways for services, feeders, and branch circuit wiring in wet or dry locations, at temperaturesnot to exceed 90℃.
Voltage rating is 600V/1000V.

This product is designed to be installed without the application of pulling lubricant.

Construction:
Conductor: Compact stranded AA-8000 series aluminum conductor material per ASTM B800, ASTM B801, ASTM B836, ASTM B901(Single Input Wire), as applicable.

Insulation:
The insulation is a low coefficient of friction, abrasion, moisture, and heat resistant thermoest cross-linked polyethylene.

Stocking most sizes in Black, Red, Blue, White, Green, Brown, Orange, Yellow, and Gray.

Standard:

• UL 44, UL 1581, UL 2556
• Federal specifications A-A-59544 and the requirements of the NEC
• Federal specification JC-30B NEC
• ANSI/NEMA WC 70-2009 ICEA S-95-658-2009
• CT Rated-Sizes 1/0 AWG and larger are rated for Cable Tray use.
• Sunlight Resistant in all color sizes 6AWG and larger.
• Basic Flame Rated(FT2) for sizes 6AWG and larger.
• RoHS compliant.

Packaging:

   (1)250 ft reels
   (2)500 ft reels
   (3)1000 ft reels
   (4)Master reels
   (5)Coils
