Application:
The product is extensively used in overbead power transission line. It improves the safely and reliance of electified wire netting.
Construction:
Conductor: 1350 AAC
Insulation: XLPE
Specification: 2*6AWG(XLPE-1.14)+1*6AWG
| AWG | Bare Neutral Messenger | Phase Conductor | Weight(kg/km) | ||
| AAC Stranding and Wire Dia.(mm) | Rated strength(1bs) | AAC Stranding and Wire Dia.(mm) | Insul. Thick.(mm) |
||
| 2*6AWG+1*6AWG | 7/1.56 | 563 | 1/4.11 | 1.14 | 146 |
Standard:
Service drop cable meets or exceeds the following ASTM specifications
Service Drop cable meets or exceeds all applicable requirements of ICEA S-76-474.
